EH04 Resistive Load Bank.
Model :
EH04Rated Voltage :
51.2VRated Output Power :
5.5kW/11KWBattery Type :
LiFePO4,16S1P
Product Features：
Model:EH04
Rated Output Power :5.5kW/11KW
Battery Type:LiFePO4,16S1P
Rated Voltage:51.2
LOAD BANK SPECIFICATIONS
| Model: | EH04 |
| Rated Output Power | 5.5kW/11KW |
| Rated Output Voltage | 230Vac |
| Input Voltage Range | (170~280Vac)+2%(90~280Vac)+2% |
| Max PV Input power | 6000W/12000W |
| Max PV Input Voltage | 500Vdc |
| MPPT Voltage Range | 120~450Vdc |
| Max PV Charging Current | 22A |
| Battery Type | LiFePO4,16S1P |
| Battery Capacity Per Pack | 100AH |
| Battery Power | 5.12KWh*(2~8 Selectable) |
| Rated Voltage | 51.2V |
| Rated Output Current | 100A |
| BMS Protective Current | 105A |
| Charging Cut-off Voltage | 57.6V |
| Charging Current | 50A/100A |
| Maximum Charging Current Of The Mains | 60A/120A |
| Peak Charging Current | 100A/200A |
| Charging Mode | Constant Current/Constant Voltage |
| Discharge Cut-off Voltage | 42.4V |
| Maximum Discharge Current | 100A/200A |
| Charging Temperature | 0~65°C(32 ~149°F) |
| Discharge Temperature | -20~65°C(-4 ~149°F) |
| Storage Temperature | >1 month，0~35'C / ≤l month，-20~45°C |
| Ambient Humidity | 15~90%Relative Humidity(No Condensation) |
| Cycle Life | 6000 Cycles(25°C),80%D0D@25°C |
The ONLB-100 100kW Resistive Load Bank is a reliable testing device for verifying generator and UPS performance under load.
Details
The ON12K-40 Resistive Load Bank is a 40kW testing device for validating generators, UPS systems, and power sources with precise resistive load simulation.
Details
The ON05K-12 Resistive Load Bank is a 40kW testing device for validating generators, UPS systems, and power sources with precise resistive load simulation.
Details
The ON12K-30V Resistive Load Bank is a 40kW testing device for validating generators UPS systems and power sources with precise resistive load simulation.
Details
The ON12K-30C Resistive Load Bank is a 40kW testing device for validating generators, UPS systems, and power sources with precise resistive load simulation.
Details
Reliable Load Banks for Generator Testing and Maintenance.
Details
