Fish Panda Marine Generator 8kW Water Cooled Diesel Generator Set for Marine & Offshore Use Price List
Panda Marine Generator 8kW Water Cooled Diesel Generator Set for Marine & Offshore Use
weight :
138kgPrime Power (kW/kVA) :
8kW/8kVAStandby Power (kW/kVA) :
8kW/8kVASize :
320×480×600mmModel :
ON80Rated Frequency :
50HZ/60HZRated Voltage :
115/230 / 120/240Marine Generator
Marine Silent Generators
Power:8kw/8kva
phase:single phase
Small size:620x480x600mm
Light weight:138kgs net weight
packing:plywood packing
Price:cheap price hot sale,color optional,for more smaller size marine ,pls contact for customized size
✔ Cost-Effective & Durable – cheap price
✔ Smart Control – Digital monitoring with remote controller
✔ Small size and light weight
Product Specification
| Model : | ON60 | ON80 | ON100 | ON120 | ON150 |
| Size : |
520×440×560mm |
620 x 480 x 600 | 640 x 510 x 600 | 660 x 510 x 600 | 760 x 560 x 600 |
| weight (kg): | 126 | 138 | 156 | 178 | 216 |
| Sound level (7m / 3m / 1m) dB： |
52 / 62 / 67
|
52 / 62 / 67 | 54 / 64 / 69 | 56 / 65 / 71 | 56 / 65 / 71 |
| Performance: |
|||||
| Nominal output(kw): |
0-6,0 (6 kVA*)
|
0-8,0 (8 kVA) | 0-10,0 ( 10 kVA) | 0-12,0 (12 kVA) | 0-15,0 (15 kVA) |
| Continuous output(kw): |
0-5.0
|
0-6.0 | 0-7.2 | 0-8.5 | 0-10.8 |
| Output voltage(V) | 230 V | 230 V | 230 V | 230 V | 230 V |
| Voltage stability | ± 3% | ± 3% | ± 3% | ± 3% | ± 3% |
| Frequency stability | 50 Hz ± 0.1 Hz | 50 Hz ± 0.1 Hz | 50 Hz ± 0.1 Hz | 50 Hz ± 0.1 Hz | 50 Hz ± 0.1 Hz |
| Continuous cunrrents(Amps) | 21.7 | 26.1 | 31.3 | 36.9 | 47.0 |
| Control | |||||
| Inverter | PMG 6000 | PMG 8000 | PMG 10000 | PMG 12000 | PMG 15000 |
| Inverter cooling | air-cooled | air-cooled | air-cooled | air-cooled | air-cooled |
| Inverter weight(kg) | 9.2 | 10.5 | 13.5 | 18 | 23 |
| Inverter dimensions(mm) | 400 x 230 x105 | 400 x 230 x105 | 400 x 230 x105 | 400 x 280 x 105 | 460 x 320 x 160 |
| Engine | |||||
| Engine manufacturer | Kubota | Kubota | Kubota | Kubota | Kubota |
| Engine type | Z482 | Z482 | D722 | D902 | D1105 |
| Engine displacement(L) | 0.479 | 0.479 | 0.719 | 0.898 | 1.123 |
| Speed(rpm) | 2200 - 2800 | 2300 - 3000 | 2280 - 3000 | 2200 - 3000 | 2200 - 2800 |
| Alternator | |||||
| Model | PMG60 | PMG80 | PMG120 | PMG150 | PMG180 |
| Rated Power(kVA) | 0-7,0 | 0-8,5 | 0-12,0 | 0-15,0 | 0-18,0 |
Marine Generator Application
Commercial Vessels: Cargo ships, tankers, container ships (main/auxiliary power)
Workboats: Dredgers, crane vessels, offshore platforms
Specialized Vessels: Cruise ships, research vessels, naval backup power
Port Equipment: Emergency power supply for docks
Customizable power, fuel type, and control systems available upon request!
Marine Generator Opitonal Engine Brands
